| Specification | Model-175 Regular |
Model-175 Hi-Speed |
Model-200 Hi-Speed |
Model-300 Hi-Speed |
Model-400 Hi-Speed |
| CUTTING CAPACITY | |||||
| Round - mm |
175 |
175 | 175 | 175 | 175 |
| Square - mm |
150 x 150 |
150 x 150 | 150 x 150 | 150 x 150 | 150 x 150 |
| Drive Motor |
0.5hp, 1440rpm |
0.5hp, 1440rpm | 0.5hp, 1440rpm | 0.5hp, 1440rpm | 0.5hp, 1440rpm |
| Coolant Pump |
0.15hp, 2800rpm | 0.15hp, 2800rpm | 0.15hp, 2800rpm | 0.15hp, 2800rpm | 0.15hp, 2800rpm |
| Blade Speed (Mtr/Min) |
25, 30, 35 |
25, 30, 40, 60 |
25, 30, 55, 75 |
25, 30, 55, 75 | 25, 30, 55, 75 |
| Size of Saw Blade - mm |
2540 x 19 x 0.9 |
2540 x 19 x 0.9 |
3000 x 25.4 x 0.9 |
3810 x 25.4 x 0.9 |
4420 x 34 x 1.1 |
| Floor Space (LxBxH)-mm |
1500 x 570 x 870 |
1500 x 570 x 870 |
1630 x 580 x 895 |
2400 x 830 x 1050 |
2700 x 830 x 1200 |
| Net Weight - Kgs. | 272 Kgs. | 322 Kgs. | 330 Kgs. | 480 Kgs. | 530 Kgs. |
