| Specification | P38 | P35 | P25 | P20 | P40-AA |
| Drilling in M.S. |
38 | 35 | 25 | 20 | 40 |
| Drilling in C.I. |
42 |
38 |
32 |
22 |
45 |
| Tapping in M.S. |
20 |
20 |
15 |
20 |
25 |
| Spindle Hole Taper |
MT-4 |
MT-3 |
MT-3 |
MT-2 |
MT-4 |
| Spindle Travel |
250 |
160 |
160 |
125 |
250 |
| Spindle Speed (RPM x Steps) |
80-2600 x 8 |
80-2600 x 8 |
100-2650 x 8 |
50-3000 x 8 |
9-70-1225rpm |
| Diameter of RAM |
78 |
72 |
72 |
55 |
78 |
| Auto Feed Range (mm x rev) |
FINE FEED |
FINE FEED |
FINE FEED |
---- |
---- |
| Max. Distance Spindle Nose to Base | 920 |
1120 |
950 |
905 |
920 |
| Distance Spindle Nose to Table |
610 |
670 |
560 |
605 |
575 |
| Distance Spindle Center to Column |
321 |
260 |
206 |
206 |
345mm Fix |
| Table Size |
425 x 425 |
355 x 355 |
330 x 330 |
260 x 260 |
450 x 455 |
| Machine Measurement (L x B x H) |
700 x 450 x 1830 |
690 x 470 x 1778 |
500 x 304 x 1600 |
480 x 330 x 1300 | 880 x 675 x 1820 |
| Diameter of Column |
110 |
180 |
90 |
75 | |
| Motor | 1.5 Hp |
1.5 Hp |
1 Hp |
0.5 Hp | 1.5 Hp |
| V-Belt | B-79 | B-60 | B-46 | A-42 | B-33 |
