| Specification | CHIPMAX - 400 | CHIPMAX - 450 | CHIPMAX - 500 | CHIPMAX - 550 |
| Center Height |
400mm | 450mm | 500mm | 550mm |
| Admit Between Center |
1000mm-7000mm | 1000mm-7000mm | 1000mm-7000mm | 1000mm-7000mm |
| Swing over bed |
800mm | 900mm | 1000mm | 1100mm |
| Swing over Cross Slide |
500mm | 600mm | 700mm | 800mm |
| Swing in Gap |
1150mm | 1250mm | 1350mm | 1450mm |
| Width of Gap |
300mm | 300mm | 300mm | 300mm |
| Width of Bed |
450mm | 500mm | 550mm | 600mm |
| Spindle Nose / Bore / Taper |
A2-8 / 104mm / MT-6 | A2-8 / 104mm / MT-6 | A2-8 / 104mm / MT-6 | A2-8 / 104mm / MT-6 |
| Spindle Speed / Range |
12 / 30-600rpm | 12 / 30-600rpm | 12 / 30-600rpm | 12 / 30-600rpm |
| Motor | 7.5hp / 10hp | 7.5hp / 10hp | 7.5hp / 10hp | 7.5hp / 10hp |
Hardened and ground bed, Hardened & Ground Spindle Nose, Norton Gear Box with Change Gears for Metric/Inch Thread, Turcite-B lining in saddle Guideways, complete with Electric Motor and Electricals, Machine is Tested to IS-1878 (Part) 1993.
Standard Accessories
Complete with electrical for 415 volts, 50 cycles, 3ph supply, Carrier Plate, Center Bush, 2Nos. MT Dead Center, Toolpost spanner, thread dial indicator, 4 way tool post and instruction manual with beam packing.Optional Accessories :
| Face Plate | 4 Jaw Independent Chuck |
Follow Rest PAD Type |
Taper Turning Attachment |
| Chuck Plate |
Steady Rest PAD Type |
Revolving Center |
Machine Lamp |
| 3 Jaw True Chuck | Steady Rest PAD Type | Motorized Apron | Coolant Pump |
